SAE ARP591 PDF
Original price was: $86.00.$49.02Current price is: $49.02.
Conventional Representation(Cancelled Nov 1959)
Description
Conventional Representation provides established drafting practice for showing various common part elements which are a compromise between complete pictorial representation and complete symbolization. The use of conventional representation materially reduces drafting time and thus increases drafting economy without impairing the clarity of the drawing.
History
| ARP591 | 1959-11-15 | Latest | Canceled |
| ISSUING COMMITTEE | EG-1 Aerospace Propulsion Systems Support Equipment |
|---|---|
| DATE | 1959-11-15 |
| DOI | |
| ISCURRENT | Current |
| PAGE | 8 |
| PUBLISHER | SAE International |
| REVISED | CANCELLED |
