SAE AS5798 PDF
Original price was: $113.00.$64.41Current price is: $64.41.
Aerospace Size Standard for Oversize O-rings
Description
This SAE Aerospace Standard (AS) is applicable to military and commercial aircraft. It specifies the dimensions, tolerances and size codes (dash numbers) for use in glands per MIL-G-5514 where squeeze at low temperature is often insufficient to provide a leak-tight seal. The dimensions and tolerances specified in this standard are suitable for any elastomeric material.
This standard should not be used as a part standard, therefore no part numbers like AS5798-001X shall be created.
Each dash number, which should be appended to an appropriate drawing or standard number, identifies one size O-ring only. An AS5798 sized O-ring is intended to replace an AS568 sized O-ring of the same dash number. An X suffix is part of the dash number to signify oversize.
Temperature limitations of 275 °F (135 °C) and coefficient of thermal expansion of 9.0 × 10-5 unit length per °F (1.6 × 10-4 unit length per °C) were used for swell calculations. Applications that exceed these values should be evaluated for excessive gland fill.
History
| AS5798A | 2025-07-16 | Latest | Reaffirmed |
| AS5798 | 2013-11-22 | Historical | Reaffirmed |
| ISSUING COMMITTEE | A-6C2 Seals Committee |
|---|---|
| DATE | 2013-11-22 |
| DOI | |
| ISCURRENT | |
| PAGE | 15 |
| PUBLISHER | SAE International |
| REVISED | REAFFIRMED |
