SAE MAP3439 PDF
Original price was: $113.00.$64.41Current price is: $64.41.
O-Ring Groove Design for Packing Preformed, Elastomeric O-Ring Seals, Static, Axial Compression, Metric
Description
This recommended practice provides the design criteria for static elastomeric O-ring seal applications, axial compression (face type) groove dimensions for aerospace metric O-ring sizes specified in MA2010. The conditions considered to formulate the design criteria are also described, e.g., seal squeeze and groove volume to accommodate O-ring swell.
History
| MAP3439A | 2021-11-23 | Latest | Revised |
| MAP3439 | 2012-12-10 | Historical | Reaffirmed |
| ISSUING COMMITTEE | A-6C2 Seals Committee |
|---|---|
| DATE | 2012-12-10 |
| DOI | |
| ISCURRENT | |
| PAGE | 15 |
| PUBLISHER | SAE International |
| REVISED | REAFFIRMED |
