SAE ANSIB92.2M PDF
Original price was: $191.00.$108.87Current price is: $108.87.
Metric Involute Splines and Inspection Standard
Description
This standard provides data and guidance for the design, manufacture, and inspection of straight, non-helical, cylindrical involute splines. It establishes a specification based on the metric module within the range 0.25-10 inclusive, relating to nominal pressure angles of 30 deg, 37.5 deg, and 45 deg. For computer programming, the term “37.5 deg” has been adopted instead of “37 deg, 30 min”.
Limiting dimensions, variations, and manufacturing tolerances and their effect on the fit between connecting co-axial spline elements, are defined and tabulated. Linear dimensions are expressed in millimeters and micrometers. Angular dimensions are expressed in degrees and decimal degrees.
History
| ANSIB92.2M | 1989-03-01 | Latest | Issued |
| ISSUING COMMITTEE | |
|---|---|
| DATE | 1989-03-01 |
| DOI | |
| ISCURRENT | Current |
| PAGE | |
| PUBLISHER | 270 |
| REVISED | ISSUED |
Please select a variation to view its pdf.
Reviews
There are no reviews yet.
